CMM Calibration and Repair
Request a quote for verification, adjustment or repair.
Request a quotation
StandardISO/IEC 17025:2017CoverageMissouri and the Greater Midwest
What a visit covers
The X, Y and Z scales are inspected and cleaned first, followed by a reader head check and an inspection of air bearings and airline condition. Geometry is checked next: straightness, linearity and squareness in the XY, ZX and ZY planes.
Length measurement error is then tested per ISO 10360-2, five calibrated lengths measured three times each across seven positions, 105 measurements in total. Probing error is tested separately per ISO 10360-5 against a dedicated test sphere.

Calibration versus repair
Some faults are corrected by geometric adjustment and a controller compensation update. Others are a parts-and-labor repair before the machine can pass verification at all.
- 01
Scale and reader head
Glass or steel scales and reader heads are cleaned, checked with an oscilloscope, and replaced when output is unstable.
- 02
Air bearings and drives
Air bearing clearance and airline supply are inspected; worn bearings and drive components are quoted as repair items.
- 03
Probe and probe head
Probe heads, styli and qualification routines are checked where probing error exceeds PFTU limits.
- 04
Error map and compensation
The volumetric compensation map is updated where the controller allows access; some controllers are OEM-locked.
- 05
Crash recovery and relocation
Machines moved or crashed are re-verified against the full geometry and length measurement error test before return to service.
Sequence of a visit
- 01
Thermal soak
Artifacts and the machine are allowed to stabilize to room temperature before testing begins.
- 02
As-found test
Geometry and length measurement error are recorded at as-found condition, before any adjustment.
- 03
Adjustment
Geometric compensation and, where accessible, the volumetric error map are updated.
- 04
As-left verification
The full test sequence is repeated and results are issued on the certificate.

Why Kansas City CMM Calibration and Repair
- 01
Artifacts matched to test
Gauge blocks, step gauges, ball bars and test spheres are selected to the length and tolerance being verified.
- 02
Out-of-tolerance reported, not hidden
As-found failures are reported with enough detail to run a reverse-traceability impact assessment.
- 03
Repair quoted separately
Adjustment within specification and a parts repair are two different line items, quoted as such.
Coverage across Missouri and the Greater Midwest
On-site scheduling is organized by region. Travel time and routing affect the date offered, particularly outside the Kansas City metro.
Other services
Discuss CMM Calibration and Repair Requirements
Describe the machine and the standard required.
